Puller ,3/4 Ton Lever Block Winch Ratchet Chain Hoist,Chain Hoist manufacturer from China Great Wall Great Wallelectrical equipment co., LTD

Puller ,3/4 Ton Lever Block Winch Ratchet Chain Hoist,Chain Hoist

Price:	20.0~50.0 USD
Payment Terms:	T/T
Place of Origin:	Hebei, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean

Packing: paper

Production Capacity: 1000set/day

Delivery Date: 7days

This Lever Block is used to connect conductor or tools when stringing works for overhead conductors,and also used to load or draw heavy materials.

Lever Block(Y-TYPE) Puller ,3/4 Ton Lever Block Winch Ratchet Chain Hoist,Chain Hoist

This Lever Block is used to connect conductor or tools when stringing works for overhead conductors,and also used to load or draw heavy materials.The length of chain can be made longer according to option.Puller ,3/4 Ton Lever Block Winch Ratchet Chain Hoist,Chain Hoist

Mode No.	Dimensions(mm)						Working load	Hook to hook	Stroke(m)	Chain dia(mm)	Weight(kg)
Mode No.	A	B	C	D	E	F	Working load	Hook to hook	Stroke(m)	Chain dia(mm)	Weight(kg)
CH-1	240	148	124	256	25	20	750	247	1.5	6.3	6.5
CH-2	330	171	141	410	32	30	1500	330	1.5	7.1	11
CH-3	400	206	185	410	43	33	3000	425	1.5	9.5	21
CH-4	550	206	248	410	50	40	6000	620	1.5	9.5*2chain	37
