Asia Cable cut,Dubai Saudi Arabia ratchet cable scissors manufacturer from China Great Wall Great Wallelectrical equipment co., LTD

Product Detail

Means of Transport: Ocean

Packing: paper

Production Capacity: 1000set/day

Delivery Date: 7days

As a professional hand pullers, hand winches, hand operated winches manufacturer, exporter, supplier and factory in China.

1. Minimized labor in operation with light weight and small size Asia Cable cut,Dubai Saudi Arabia ratchet cable scissors

2. Easy for one hand operation

3. Rachet controlled with relaease option in every cutting position

4. Endurance and antirust by enhanced surface processing and heat-treatment technology

5. Product supplied with blister card Asia Cable cut,Dubai Saudi Arabia ratchet cable scissors

Name	Product No.	Model	Overall dimension		Weight
J13 cable cutter	JD011-1	J13	350(510)12045(mm)		1.5kg
Application	It can cut steel strand below 150mm²,mainly used for cutting steel wire,could not be used for cutting copper conductor cable.
J30 cable cutter	JD011-2	J30	400(580)16060(mm)		3.5kg
Application	It can cut steel strand below 100mm²,or ACSR below 630mm²,it is forbidden to be used for cutting copper cable.
J25 cable cutter	JD011-3	J25	745130630(mm)		4kg
Application	It can cut steel strand below 150mm²,or ACSR below 800mm²
J50 cable cutter	JD011-4	J50	375(540)15040(mm)	2.3kg
Application	It can cut ACSR below 1440mm²,it is forbidden to be used for cutting copper cable.
J14 cable cutter	JD011-5	J14	350(510)12045(mm)	1.5kg
Application	It can cut steel wire whose diameter is below 20mm,keep the cleaning of gear.
